- Usage:Outdoor
- Tube Chip Color:FULL COLOR
- Display Function:Video
- Warranty: 3 Years:LED chip: Epistar
- Certificate: CCC CE ROHS ISO:Life span: 100000 Hours
- Screen Dimension: Customized:Cabinet material: Die-casting Aluminum
- Application: Rental:Control system: Linsn /Nova
- Input Voltage (AC): 110V / 240V:Grey Scale: 16bit
- Screen Dimension:500*500mm
- Pixels:4.81mm
- Application:outdoor
- Color:full color
- Panel Size:500*1000mm
- Pixel Pitch:4.8mm
- Place of Origin:Guangdong, China (Mainland)
- Model Number:HO4.8
- Brand Name:LEDFUL
H Series
Fashion LED Event LED Display
HI2.6 | HI2.8 | HI2.9 | HI3.9 | HI4.8 HO3.9 | HO4.8 | HO5.9 | HO6.2
▲Front Maintenance
▲Curved Installation
▲No Light Leakage
▲Climbing support
▲Light and Thin
Product Name | HO4.8 |
Pixel Pitch(mm) | 4.81mm |
Pixel Matrix Per Sq.m | 43264 |
Pixel Configuration | SMD2727/1921 |
Brightness (nits) | ≥4500 |
Scan | 43113 |
Cabinet Resolution | 104×208 |
Power Con. (Max / Avg) | 740 / 220 w/sq.m |
Refresh Rate (HZ) | 1920 |
Cabinet Weight | 15kg / 33.06Ib ( Die-casting Aluminum) |
Cabinet Material | Die-casting Aluminum |
Module Dimension | 250x250mm / 0.82x0.82feet |
Cabinet Dimension | 500x1000x83mm / 1.64x3.28x0.27ft |
Service Access | Front / Rear |
Rotation Angle | -10° and +10° |
Grey Scale (bit) | 16 |
Viewing Angle (H/V) | 160 / 160 |
IP Rate | IP65 |
Input Voltage (AC) | 110 / 240 |
Details
Front Maintenance
The magnet LED modules can be dismantled by tools on front side.
Curved Installation
Curved with every 2.5° between -10°and 10°, which can make convex and concave.
Climbing Support
Climbing structure can help you make convenient maintenance
Ultra Fast Response
No light leakage trouble
No light leakage design with specific strips on side of cabinet and behind neighbour module.
Wide Viewing Angle
Faster & Easier Installation
Hanging or stacking, D series with light and thin features makes installation faster and easier.
Accessories
Packaging
1.Plywood box: Covered with eco-friendly wood and aluminum, and pearl cotton is placed inside, which is resistant to pressure, shock and moisture, and effectively prevents damage during transportation;
2.Flight case: EPE(Expandable Polyethylene) protection, anti-pressure, anti-shock , ensure goods safety.
Shipping
1. By sea or by air;
2. Customer specified freight forwarder or negotiable mode of transport;
3. Delivery Time: 15-25 days for batch goods.
Flight case
Plywood box
EPE(Expandable Polyethylene)
1)Reply your inquiry in 24 working hours.
2)Customized design is available ,OEM & ODM are welcomed.
3)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs
4)Guidance service: We can guide on line if customers have questions about the installation and usage.
For large project, we provide your engineer free training, or our engineer can go to customer's country for on-site guidance.
5) Warranty period: 3 years after shipment.
Q1. Are you trading company or manufacturer ?
A: We are led display manufacturer
Q2: What is the control system?
A: We use Nova control system.
Q3. How about your delivery time?
A: Generally, it will take 15 to 25 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q5: How can you ensure your led display product quality?
A: LEDFUL Opto-electronics have been enrolled in led display industry for almost 10 years, and professional R&D team and skilled QC team with standard process to assure quality products.
